Ultra DBI™
The Ultra DBI™ is designed with the following in mind to help optimize department space by accommodating a range of procedures, including upright and decubitus stereotactic breast biopsy and mammography, on a bariatric-capable platform. It is intended to potentially support improved throughput and continuity of care.
The chair features removable and interchangeable armrests, patient back support, and an instrument tray. Its adjustable design is aimed at providing comfort for patients and offering flexibility to clinicians during breast imaging and biopsy procedures.
Optional features of our Ultra DBI™ may be pictured
Our Ultra DBI™ is designed for:
• Radiologists
• Surgeons
Ultra DBI™ Specification Sheet
| Height Positioning | 24″ to 35.5″ |
| Maximum Patient Capacity | 500 lbs. |
| Trendelenburg | 15° to -15° |
| Fowler | 90° |
| Width | 28″ |
| Length | 76″ |
| Length of Wheel Base | 30″ |
| Warranty | 2 Years |
| Foam | TB 117-2013 Section E |
| Electrical | 100-230 VAC,50/60 Hz, Max 5 A |
| Vinyl | California T.B., 117-2013, NFPA 260- Cover, Fabric – Class I UFAC, Fabric – Class I |
Compare Mammography Chair Standard Features
| UltraMamm™ | Ultra DBI™ | |
| Height Positioning | 22″ to 38″ | 24″ to 35.5″ |
| Maximum Weight Capacity | 500 lbs. | 500 lbs. |
| Width | 33.5″ with arm rests 28.5″ without arm rests | 28″ |
| Length | 75″ with Head Support 64.5″ without Head Support | 76″ |
| Warranty | 2 Years | 2 Years |
| Foam | TB 117-2013 Section E | TB 117-2013 Section E |
| Electrical | 100 – 240 VAC, 50/60 Hz, 4.5 Max | 100-230 VAC,50/60 Hz, Max 5 A/td> |
| Vinyl | TB 117-2013, NFPA 260 Cover Fabric – Class 1, UFAC Fabric – Class 1 | California T.B., 117-2013, NFPA 260- Cover, Fabric – Class I UFAC, Fabric – Class I |
